نام قطعه
JF050TN43-GQ(480*800)
نام کارخانهای
JF050TN43-GQ(480*800)
برند
CHINA
پکیج
LCD
بستهبندی
Tape & Reel
عنوان گروه
دیتاشیت
| Features | ||
|---|---|---|
| DISPLAY SIZE | 5.0 INCH | |
| Interface Type | Parallel RGB (1 ch, 8-bit) , 40 pins FPC | |
| RESOLUITION | 800(RGB)×480 [WVGA] | |
| ACTIVE AREA | 108(H)×64.8(V) mm | |
| Outline Size | 118.15(H)×77.55(V) ×3.3(D) mm | |
| BRIGHTNESS | 350 cd/m² | |
| POWER SUPPLY | 3.3V | |
| Touch Panel | Without Touch | |
| Light Source (Backlight) | WLED , 20K hours , W/O Driver | |
| VIEWING ANGLE | 70/70/50/70 (L/R/U/D) | |
| Minimum Operating Temperature | -20 C ° | |
| Maximum Operating Temperature | 70 C ° | |
| Display Mode | TN, Normally White, Transmissive | |
| Contrast Ratio | 500:1 | |
| Brand | CHINA | |
| Package | LCD | |
موجود
یوان
100
9150000 ریال
تحویل 35 روزه
